Cudy GS1005PTS1 5-Port Gigabit PoE+ Switch with 1 SFP Slot

Cudy GS1005PTS1 managed switch Review in Bangladesh
The Cudy GS1005PTS1 5-Port Gigabit PoE+ Switch with 1 SFP Slot is available now in Bangladesh. Get the original Cudy products at the most affordable price only at Ajkershop and enjoy the quality with the promise of the best customer service in Bangladesh.

• 120 watts PoE power supply
• 4 Gigabit PoE+ ports and 1 Gigabit Ethernet ports+1Gigabit SFP
• Extend mode support remote PoE feeding up to 250m
• VLAN mode isolates each PoE Ports for security
• Watchdog reactivates the abnormalPD by resuming POE power


Specifications for the Cudy 5-port PoE switch with SFP:
Brand: Cudy
Model: GS1005PTS1

Main Features:
Switching Capacity: 12 Gbps
Throughput: 8.928 Mpps
Packet Buffer: 1 Mb
MAC Address: 2K
Jumbo Frame: 9216 bytes
Transfer Mode: Store and forward
MTBF: 100,000 hours

Network Protocol:
IEEE 802.3 (10Base-T)
IEEE 802.3u (100Base-TX)
IEEE 802.3ab (1000Base-TX)
IEEE 802.3z (1000Base-FX)
IEEE 802.3x (Flow control)

PoE Protocol:
IEEE 802.3af: 15.4W
IEEE 802.3at: 30W
IEEE 802.3at (4 Pair): 60W

Network Medium:
10Base-T: Cat3, 4, 5 or above UTP (≤100m)
100Base-TX: Cat5 or above UTP (≤100m)
1000Base-TX: Cat5 or above UTP (≤100m)

Optical Media:
Multimode fiber: 50/125, 62.5/125, 100/140μm
Single-mode fiber: 8/125, 8.7/125, 9/125, 10/125μm

Hardware Features:
PWR (Power supply):
Lighting: Powered
Un-light: No Power
Mode (DIP):
Lighting: VLAN
Un-light: Default
Flashing: Extend
1-6 Green (Link & Data):
Lighting: Connecting
Flashing: Data Transmit
Un-light: Disconnect

DIP Switch:
VLAN: Port isolation mode (PoE ports 1-4 communicate only with UP-link port)
Default: All ports can communicate, transmission distance within 100 meters
Extend: Link extension mode for ports 3-4, PoE supply and transmission distance up to 250 meters at 10 Mbps

Power:
Input Voltage: AC 100-240V

Environment:
Working Temperature: -20~50°C
Storage Temperature: -40~85°C
Working Humidity: 10%~90%, non-condensing
Storage Humidity: 5%~90%, non-condensing
Working Height: Max 10,000 feet
Storage Height: Max 10,000 feet

Dimensions (L×W×H):
Product Dimension: 200×118×44 mm
Package Dimension: 245×190×60 mm

Weight:
N.W.: 0.6 kg
G.W.: 0.9 kg

Package Content:
Switch 1 pc
Power cord 1 pc
User manual 1 pc
Certification 1 pc
Warranty: 1-Year Brand Warranty

Cudy GS1005PTS1 Gigabit PoE+ switch Price in Bangladesh

What is the price of Cudy GS1005PTS1 Gigabit PoE+ switch Price in Bangladesh?
The latest price of Cudy GS1005PTS1 5-Port Gigabit PoE+ Switch with 1 SFP Slot in Bangladesh is ৳4490. you can buy the Cudy GS1005PTS1 managed switch in Bangladesh at the best price from our website.
